SKU Code
10100TBP
Bar Code
5055331828798
Brand
Pack Type
TIMpac
Pack Qty
2
Pallet Qty (pcs)
12,000
Material
Carbon Steel
Finish
Zinc
Corrosion Rating (1-5)
1 - Clean, dry &
MOQ
1
MOQ Increment
1
Head Type
Chamfered
Thread Type
Metric
Packs per Carton
10
Packs per Pallet
6,000
Pack Dimensions L x W x H (mm)
15 x 90 x 163
Pack Weight (kg)
0.120
Thread Ĝ (mm)
M10
Substrates
Concrete
DIN
DIN 125-A, DIN 934
Washer Size (mm)
M10 x 21
Nut Type
Hex Full
Included Items
M10 Hex Full Nuts &
Washer Type
Form A
Nut Size (mm)
M10
Nut Socket Size (mm)
17
Fixture Hole Size Ĝ (mm)
12.0
MFT (mm)
35
Thread Ĝ x L (mm)
M10 x 100
A versatile, torque controlled through fixing for use in a wide range of anchoring applications into concrete. NOTE: If no torque wrench is available, tighten the nut 3 to 4 full turns from finger tight.
